Sat-TV - DS6 PRO | Maritime TV Antenna

Product Description

Maritime TVRO antenna for seamless TV reception with 60 cm diameter dish and 3-axis motion system.

EPAK DS6 PRO is the right choice for those who want a reliable and powerful television reception system on board, keeping an eye on the dimensions of the antenna.

With its 60 cm diameter dish, the DS6 PRO offers you a seamless signal reception and can face the toughest weather conditions while moving in opens seas.

Its contained dimensions allow you to use the DS6 PRO on almost every kind of vessel and the implementation of our Diversity Kit is the perfect solution for getting rid of all bothering blind spots.

Storing a large variety of different satellites, the DS6 PRO is the maritime satellite system that brings TV entertainment to your boat: in your language and wherever you want.



Small dimensions

Rugged and reliable, the DS6 PRO is indeed extremely light-weighted and its very contained dimensions fit the needs of even the smallest boats.



SIM LTE

You can insert two local SIM cards into the antenna's control unit to access low-cost, high-speed Internet when a 3G/4G network is available.



Easy installation: no crane needed

Due to its restrained weight, the DS6 PRO can be easily transported and refitted.



Sensor-based satellite reacquisition

Instant relock feature after passing obstacles like bridges, buildings, trees etc.



All your favourite channels

A large variety of satellites can be remotly stored   by the user at anytime through the antenna Web Interface, allowing you to watch all your favourite TV rograms in your language.



Multi-user kit

Through connection of multi-user kits an unlimited number of TV places can be served.



KEY FEATURES:

- 3-axis motion system + auto skew

- Elevation range from -15° to +120°

- Tracking speed up to 50°/s per axis

- LTE Plug & Go SIM cards

- LEO, MEO, GEO tracking supported

- Easy to install

- Quattro LNB, for connecting as many receivers you want

- High-quality material for operating even under the hardest conditions

- Unlimited azimuth range (no cable unwrap)
